Thickness : 20.00 mm Width :53.00 mm
Height (JNS35/7.5, JNS35/15, JNS32) : 43.90mm / 51.40mm
| Rigid Conducto(mm2) | - |
| Flexible Conductor(mm2) | - |
| AWG | 2-16 |
| Rated Voltage (V) | 600 |
| Rated Current (A) | 75 |
| Rated Connectiong Capacity(mm2) | 21 |
| Rated Surge Voltage | 6000 |
| Contamination Class | Ⅱ |
| Overvoltage Category | Ⅲ |
| Material Grop | Ⅱ |
| Insulation Material | PA |
| Inflammability Class | UL94,V-0 |
| Stripping Length mm | 16 |
| Screw M | 6 |
| Torque N.m | 3.9-5.4 |
| Packing Quantity PCS | 10 |
| End Cover | DG801 |
| Fixed Bridge | SG801 |
| Insertion Bridge | - |
| Switch bar for 2 TB | - |
| Separating Disk | - |
| Partition Plate | - |
| Test Socket | - |
| Marker Strip | BS800 |
| Marker Carriers | RBJ1 |
| Rail Stator | GD001 |
| Rail Stator | A047-9 |
| Rail Stator | A049-9 |
| MountingRail | JNS35/7.5 |
| MountingRail | JNS35/15 |
| MountingRail | JNS32 |
